REMO100

Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)

RM 299.50
Quantity
+
Model
10348378
Brand
NO BRAND
Status
Available Now
Delivery
Usually ships within 2-4 days
Delivery Fee
West Malaysia - RM 6.00
East Malaysia - RM 19.40
Rewards
299 Points
Highlights
  • Long-range transmitting distance of 3.5KM. Provide you with wifi signal with high transmission efficiency.
  • Stability has been improved by 80% with 9531 chip. Point-to-point connection makes transmission smoother, signal more stable and having more advantages in monitoring.
  • The mainboard core has passed industrial processor. All parts are new and use AR9344 industrial chip with high transmission efficiency and high data throughput.
Product Information

What's in the box:

Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)

Especially designed for elevator monitoring and control.
Features:
High Performance with 300Mbps, 680MHz and 64M.
Long-range transmitting distance of 3.5KM. Provide you with wifi signal with high transmission efficiency.
Stability has been improved by 80% with 9531 chip. Point-to-point connection makes transmission smoother, signal more stable and having more advantages in monitoring.
The mainboard core has passed industrial processor. All parts are new and use AR9344 industrial chip with high transmission efficiency and high data throughput.
Convenient installation. Plug & Play. Wireless access(A+B) automatically.
Widely compatitble with Windows7,Windows8,WindowsXP,Windows2000,Mac OS X,Linux and so on.
Long durability and high quality material of ABS lead to rain resistance, thunder resistance, freeze resistance and sun resistance.
Specification:
Chipset AR9531
FLASH * DDR2 FLASH 8MB * DDR2 64MB
Interface 10/100Mbps WAN*1 LAN*1
Power Supply POE 24V 1A
Antenna Spec frequency range 23002800MHz
Polarization direction Horizontal / vertical
Gain 14DBi
Management &
Security
Telnet Support
MAC address control Support
Management based on WEP Support
Encryption WEP encryption 64/128bits,WPA,WPA2,802.1x

Work / Storage environment
working temperature -3070
Storage temperature -3065
Humidity (not concentrated) 95%






















frequency range 2.4GHz frequency range2.4~2.4835GHz
transmission speed 2.4GHz transmission speed 11b1/2/5.5/11Mbps
11g6/9/12/18/24/36/48/54Mbps
11nMax. 300Mbps
Working channel 2.4GHz transmission speed 131~13
Spread frequency technique DSSSDirect sequence spread spectrum
Data Modulation 11bCCKQPSKBPSK
11gOFDM
11nQPSKBPSK16-QAM64-QAM
Medium access protocol CSMA/CA with ACK
Data Encryption WPA-PSK/WPA2-PSKWPA/WPA2WEP
Transmission
Power
@252dB

802.11b
6-24Mbps 212dBm
36-48Mbps 212dBm
54Mbps 212dBm

802.11g
6-24Mbps 192dBm
36-48Mbps 192dBm
54Mbps 192dBm

802.11n
HT20(MCS0-MCS7) 172dBm
HT40(MCS0-MCS7) 172dBm
Receiving sensitivity 802.11n 802.11g 802.11b
-86dBm @ MCS0 - 90dBm @ 6Mbps - 92dBm @ 1Mbps
-65dBm @ MCS7 - 68dBm @ 54Mbps - 85dBm @11Mbps
Size 310*95*75mm
Weight 0.45kg
Packing List 1 * Outdoor CPE
1* 24V POE power
1* Hose Clamp
1* Instruction










































Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)
Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)
Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)
Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)
Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)
Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)
Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)
Wireless Outdoor CPE Bridge Outdoor AP Router WDS Network Bridge 3.5KM Directional Antenna 300Mbps 2.4G 14dBi Wireless Access(A+B) (Standard)
