What's in the box:
1 x TL-ER5120 Switch1 x Power Cord1 x Rack-mount Kit1 x Installation Guide
Product details ofTP-LINK TL-ER5120 Gigabit Load Balance Broadband Router Desktop Switch
- 64-bit dedicated dual-core processor and 2 Gbit DDRIII high-speed memory for outstanding performance
- Equipped with 1 Gigabit WAN port, 1 Gigabit LAN port, and 3 adaptable Gigabit WAN/LAN ports
- Load Balancing automatically selects the best route to the destination according to the load
- The captive portal provides convenient guest authentication while promoting your business
- Abundant security features including ARP Inspection, DoS Defense, URL/Keyword Domain Filter and Access Control
- Professional 4KV lightning protection keeps your investment safe1
| Standards and Protocols | IEEE 802.3, IEEE802.3u, IEEE802.3ab TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, PPTP, L2TP |
|---|---|
| Interface | 1 Gigabit WAN port 3 Gigabit LAN/WAN ports 1 Gigabit LAN port |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) EIA/TIA-568 100 STP (Max 100m) 100BASE-TX: UTP category 5, 5e cable (Max 100m) EIA/TIA-568 100 STP (Max 100m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m) |
| Button | Reset Button |
| Power Supply | Internal Universal Power Supply AC100-240V~ 50/60Hz Input |
| Flash | 32MB |
| DRAM | DDRIII 256MB |
| LED | PWR, SYS, Link/Act, Speed, WAN |
| Dimensions ( W x D x H ) | 17.3 x 8.7 x 1.7 in.(440x220x44 mm) 19-inch Standard Rack-Mount Width, 1U Height |
| PERFORMANCE | |
|---|---|
| Concurrent Session | 150K |
| NAT Throughput | 800Mbps |
| NAT(iMIX) | 703Mbps |
| NAT(DHCP) | 934Mbps |
| NAT(PPPoE) | 868Mbps |
| BASIC FUNCTIONS | |
|---|---|
| WAN Connection Type | Static/Dynamic IP PPPoE/Russian PPPoE PPTP/Russian PPTP L2TP/Russian L2TP Bigpond Cable |
| MAC Clone | Modify WAN MAC Address |
| DHCP | DHCP Server/Client DHCP Address Reservation |
| IPv6 | IPv6 Support |
| VLAN | 802.1Q VLAN, Port VLAN |
| IPTV | Bridge, Custom |
| TRANSMISSION | |
|---|---|
| Load Balance | Intelligent Load Balance Link Backup (Timing, Failover) Online Detection |
| NAT | One-to-One NAT Multi-nets NAT Virtual Server Port Triggering FTP/H.323/SIP/IPsec/PPTP ALG UPnP |
| Routing | Static Routing Policy Routing |
| Session Limit | IP-based Session Limit |
| Bandwidth Control | IP-based Bandwidth Control |
| SECURITY | |
|---|---|
| Filtering | MAC Filtering URL/Keywords Filtering |
| ARP Inspection | Sending GARP Packets ARP Scanning by WAN/LAN IP-MAC Binding |
| Attack Defense | TCP/UDP/ICMP Flood Defense Block TCP Scan (Stealth FIN/Xmas/Null) Block Ping from WAN |
| Access Control | Source/Destination IP Based Access Control |
| AUTHENTICATION | |
|---|---|
| Web Authentication | Local User Authentication Radius Sever Authentication Onekey Online |
| MANAGEMENT | |
|---|---|
| Service | Dynamic DNS (Dyndns, No-IP) |
| Maintenance | Web Management Interface Remote Management Export & Import Configuration SNMP Diagnostics(Ping & Traceroute) NTP Synchronize Syslog Support |
| OTHERS | |
|---|---|
| Certification | FCC, RoHS |
| Package Contents | TL-ER5120 Power Cord Rack-mount Kit Installation Guide |
| Environment | Operating Temperature: 0~40 (32~104) Storage Temperature: -40~70 (-40~158) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
