HIGHLIGHTS

9 10/100/1000Mbps RJ45 ports, 1 Gigabit SFP port
With 8 PoE+ ports, transfers data and power on one single cable
Works with IEEE 802.3af/at compliant PDs and expands office network
802.1p/DSCP QoS enable smooth latency-sensitive traffic
High PoE power budget with up to 30W for each PoE port and 63W for all PoE ports
Easy to use, with no configuration and installation needed

SPECIFICATIONS

Interface:
8 PoE+ 10/100/1000Mbps RJ45 Ports
1 10/100/1000Mbps RJ45 Port
1 Gigabit SFP Slot
Fan Quantity: Fanless
External Power Supply:
External Power Adapter(Output: 53.5VDC/1.31A)
Max Power Consumption:
7.11 W (220/50Hz. no PD connected)
78.13 W (220/50Hz. with 63W PD connected)
Max Heat Dissipation:
24.25 BTU/h (no PD connected)
266.42 BTU/h (with 63W PD connected)
PoE Ports (RJ45):
Standard: 802.3af/at compliant
PoE Ports: 8 Ports
Power Supply: 61 W*
Advanced Features:
Compatible With IEEE 802.3af/at Compliant PDs
EEE802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping
Transmission Method: Store-And-Forward
Dimensions ( W x D x H ): 209 126 26 mm
Certifications: CE

WHAT'S IN THE BOX

1 TL-SG1210P
1 Power Adapter
1 Installation Guide

WARRANTY INFORMATION / RETURN / REPLACEMENT / REFUND

3 years warranty
based on the S/N (serial number) or the purchase invoice date
No Wanranty-Product is physical damaged, watered, burned, or other manmade damaged
No Wanranty-Model is opened, or serial number, missing, or parts of the model missing

Kindly take a photo of the item and provide the order number to our customer service agent for further details
