HIGHLIGHTS

16 10/100/1000Mbps RJ45 ports
Provides network monitoring, traffic prioritization and VLAN features
Green technology reduces power consumption
Simple network set-up on top of plug-and-play connectivity
Web-based user interface and management utility simplify configuration

SPECIFICATIONS

Interface: 16 10/100/1000 Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports
Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Fan Quantity: Fanless
External Power Supply: External Power Adapter(Output: 12VDC/1.0A)
LED Indicator: System Power; Link/Act indicators per port built into each RJ-45 port
Max Power Consumption: 9.19W(220V/50Hz)
Max Heat Dissipation: 31.36BTU/h
Switching Capacity: 32Gbps
Packet Forwarding Rate: 23.81Mpps
Quality of Service: Support Port-based/802.1p/DSCP priority, Support 4 priority queues, Rate Limit, Storm Control
L2 Features: IGMP Snooping V1/V2/V3,Static Link Aggregation, Port Mirroring, Cable Diagnostics, Loop Prevention
VLAN: Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs), MTU/Port/Tag VLAN
Transfer Method: Store and Forward
Dimensions ( W x D x H ): 11.3 4.4 1.0 in. (286 111.7 25.4 mm)
Certifications: CE

WHAT'S IN THE BOX

1 TL-SG116E
1 Power Cord
1 Installation Guide
1 Rubber Feet

WARRANTY INFORMATION / RETURN / REPLACEMENT / REFUND

3 years warranty
based on the S/N (serial number) or the purchase invoice date
No Wanranty-Product is physical damaged, watered, burned, or other manmade damaged
No Wanranty-Model is opened, or serial number, missing, or parts of the model missing

Kindly take a photo of the item and provide the order number to our customer service agent for further details
