What's in the box:

L925B Fiber Optic Quick Connector Easy-Connect Optical Fiber Mechanical Splices for Drop Cable (Standard)

Optical fiber cold connector is also called optical fiber quick connector, used for optical fiber-butt-fiber or fiber pigtail. Application: for FTTH engineering and optical cable repairing.

Features:
It is simpler and faster to operate, adopts V-groove-butt technology, suitable for single-mode and multi-mode optical fiber connection.
Fixture tools not needed, the operation time is less than 2 minute.
It does not rely too much on the flatness of the fiber end face cutting, which greatly reduces the requirements for the operator's proficiency.
The box structure design, nice sealing performance, matching fluid is not easy to lose, weather resistance is strong.
Suitable for any combination of 0.25mm optical fiber and 0.9mm optical fiber.

Specifications:
Main material: plastics
Insertion loss: 0.10dB
Return loss: -40dB
Fiber diameter: 125um
Bare fiber tightening force: >5N
Tight wrapping force: >8N
Package size: 63 * 53 * 15mm / 2.5 * 2.1 * 0.6in
Package weight: 40g / 1.4ounce

Packing List:
5 * Connector
1 * Storage Box
1 * User Manual
