*Model Indoor (50Hz) CS-XPU10WKH-1

Outdoor (50Hz) CU-XPU10WKH-1

Refrigerant Type R32

Cooling Capacity (min-max) kW 2.84 (0.90-3.40)

(min-max)Btu/h 9,680 (3,070-11,600)

EER (min-max) Btu/hW 13.26 (13.64-11.26)

(min-max) W/W 3.89 (4.00-3.30)

CSPF 5.63

Electrical Data Voltage (V) 230

Running Current (A) 3.3

Power Input (W) 730 (225-1,030)

Moisture Removal L/h 1.7

Pt/h 3.6

Air Circulation Indoor m/min (ft/min) 10.3 (365)

Outdoor m/min (ft/min) 27.6 (970)

Noise Level Indoor (H/L/Q-Lo) (dB-A) 38/26/19

Outdoor (H / L) (dB-A) 47

Dimensions Height (mm) 290 (511)

Height (inch) 11-7/16 (20-1/8)

Width (mm) 779 (650)

Width (inch) 30-11/16 (25-19/32)

Depth (mm) 209 (230)

Depth (inch) 8-1/4 (9-1/16)

Net Weight Indoor kg (lb) 8 (18)

Outdoor kg (lb) 18 (40)

Refrigerant Pipe Diameter Liquid Side (mm) 6.35

Liquid Side (inch)

Gas Side (mm) 9.52

Gas Side (inch) 3/8

Pipe Extension Chargeless Pipe Length (m) 7.5

Maximum Pipe Length (m) 20

Maximum Elevation Length (m) 15

Additional Refrigerant Gas* (g/m) 10

Power Supply Indoor

Cleaner Air nanoeX Yes

nanoe-G Yes

Anti-Dust Coating No

Dust Sensor No

Odour-Removing Function Yes

Removable, Washable Panel Yes

Comfort Radiant Cooling No

iAUTO-X No

iAUTO No

ECONAVI No

ECO Mode with A.I. Yes

Temperature Wave No

SLEEP Yes

Inverter Control Yes

Powerful Mode Yes

Quiet Mode Yes

Soft Dry Operation Mode Yes

Personal Airflow Creation No

Airflow Direction Control (Up Down) Yes

Manual Horizontal Airflow Direction Control Yes

Convenience 24-Hour Dual ON OFF Real Setting Timer Yes

24-Hour ON OFF Real Setting Timer No

LCD Wireless Remote Control Yes

Wireless LAN Remote Control For Internet Connection Yes (Optional)

Wired Remote Control Yes (Optional)

Reliability Random Auto Restart (32 Restart Patterns) Yes

Blue Fin Condenser Yes

Long Piping (Numbers indicate the maximum pipe length) 20m

Top-Panel Maintenance Access Yes

Self-Diagnostic Function Yes

Model

Indoor (50 Hz)

CS-XPU13XKH-1

Outdoor

CU-XPU13XKH-1

Cooling Capacity (min-max)

3.66 (1.02-4.10) kW

12,500 (3,480-14,000) Btu/h

EER (min-max)

12.63 (12.65-12.07) Btu/hW

3.70 (3.71-3.53) W/W

CSPF

5.46 W/W

Electrical Data

Voltage

230 V

Current

4.4 A

Power Input (min-max)

990 (275-1,160) W

Moisture Removal

2.1 L/h

4.4 Pt/h

Air Circulation

Indoor

11.0 m/min (390 ft/min)

Outdoor

30.6 m/min (1,080 ft/min)

Noise Level

Indoor (H / L / Q-Lo)

40/26/21 dB(A)

Outdoor (H)

48 dB(A)

Dimensions (Indoor)

Height

290 mm (11-7/16 inch)

Width

779 mm (30-11/16 inch)

Depth

209 mm (8-1/4 inch)

Dimensions (Outdoor)

Height

542 mm (21-11/32 inch)

Width

780 mm (30-23/32 inch)

Depth

289 mm (11-13/32 inch)

Net Weight

Indoor

8 kg (18 lb)

Outdoor

22 kg (49 lb)

Refrigerant Pipe Diameter

Liquid Side

6.35 mm (1/4 inch)

Gas Side

9.52 mm (3/8 inch)

Pipe Extension

Chargeless Pipe Length

7.5 m

Maximum Pipe Length

20 m

Maximum Elevation Length

15 m

Additional Refrigerant Gas*

10 g/m

Power Supply

Indoor

Comfort Features

ECO Mode With A.I.

Yes

Inverter Control

Yes

Powerful Mode

Yes

Sleep Mode

Yes

Quiet Mode

Yes
