Specifications

Model Indoor (50Hz): CS-PN12WKH-1 Outdoor (50Hz): CU-PN12WKH-1 Refrigerant Type R32 Cooling Capacity (min-max) kW: 3.52 (min-max)Btu/h: 12,000 EER (min-max) Btu/hW: 11.21 (min-max) W/W: 3.29 CSPF: 3.43 Electrical Data Voltage (V): 230 Running Current (A): 4.8 Power Input (W): 1,070 Moisture Removal L/h: 2.0 Pt/h: 4.2 Air Circulation Indoor m3/min (ft3/min): 11.6 (406) Outdoor m3/min (ft3/min): 29.8 (1,050) Noise Level Indoor (H/L/Q-Lo) (dB-A): 41/29 Outdoor (H / L) (dB-A): 51 Dimensions Height (mm): 290 (542) Height (inch): 11-7/16 (21-11/32) Width (mm): 779 (780) Width (inch): 30-11/16 (30-23/32) Depth (mm): 209 (289) Depth (inch): 8-1/4 (11-13/32) Net Weight Indoor kg (lb): 8 (18) Outdoor kg (lb): 26 (57) Refrigerant Pipe Diameter Liquid Side (mm): 6.35 Liquid Side (inch): Gas Side (mm): 9.52 Gas Side (inch): 3/8 Pipe Extension Chargeless Pipe Length (m): 7.5 Maximum Pipe Length (m): 20 Maximum Elevation Length (m): 15 Additional Refrigerant Gas* (g/m): 10 Power Supply: Indoor Cleaner Air Odour-Removing Function: Yes Removable, Washable Panel: Yes SLEEP: Yes Powerful Mode: Yes Quiet Mode: Yes Soft Dry Operation Mode: Yes Airflow Direction Control (Up Down): Yes Manual Horizontal Airflow Direction Control: Yes 24-Hour ON OFF Real Setting Timer: Yes LCD Wireless Remote Control: Yes Wired Remote Control: Yes (Optional) Reliability Random Auto Restart (32 Restart Patterns): Yes Blue Fin Condenser: Yes Long Piping (Numbers indicate the maximum pipe length): 20m Top-Panel Maintenance Access: Yes NOTE Please do not use copper pipes that are less than 0.6mm in thickness. *When pipes are not extended from the standard pipe length, the required amount of refrigerant is already in the unit.
