GENERAL SPECIFICATIONS
- Speaker Type : 8" Active + 8" Passive
- Speaker Size : 203.2mm + 203.2mm
- Impedance : 2 Ohms
- RMS Power Rating : 300 Watts
- MAX Power Handling : 1200 Watts
- Sensitivity (1w/1m) : 83dB
- Frequency Response: 30Hz - 350Hz
AMPLIFIER SPECIFICATIONS
- Amplifier Class : Class D
- Amplifier Type : Subwoofer Monoblock
- Number of Channels: 1
- Minimum Impedance: 2 Ohm
- Signal to Noise Ratio : >80dB
- Efficiency @ 4 Ohm : 75%
- Total Harmonic Distortion (THD) : <0.5%
- Low Level Input Range : 200mv - 6V
- High Level Input : 2 - 9V
- Auto Turn-On : Yes (Hi-Level Input)
- Selectable X-Over : LPF Fixed
- X-Over Filter Range : 35Hz - 180Hz
- Bass Boost Range : 0 - 12dB
- Bass Boost Frequency : 50Hz
- Phase Selector: 0~180
- LED Indicator: Power | Protection
- Power Input Terminal Size : 8 GA
- Fuse Size: 30A
- Remote Level Control : Yes (Dash Mount NOT Included)
- Thermal Protection : Yes (>75C)
- DC Output Protection : Yes (>2V)
- Short Circuit Output Protection: Yes
- Voltage Input Protection : Yes (>17vdc)
SPEAKER SPECIFICATIONS
- Voice Coil Diameter : 1.52" / 38.6mm
- Voice Coil Former Material : Aluminium
- Winding Material : Cooper
- Cone Material : Non-Pressed Paper
- Dust Cap Material : Paper
- Surround Material : Rubber
- Basket Material : Steel
- Magnet Material : Ferrite
- Magnet Weight : 32 Oz / 914 g
