Specifications

Compressor

Type : Non Inverter

Model

Indoor/Outdoor : HSU-19LPB21

Capacity

Capacity (W) : 5275

Capacity (Btu) : 18000

Power input (W) Cooling : 1795

CSPF : 3.20

Star Rating : 3

Running current (A) Cooling : 7.90

Power supply (Ph/V/Hz) : 1/220-240/50

Air circulation (m/h) : 1,100

Moisture removal (10m/h) : 2.0

Refrigerant : R32

Refrigerant pipe (mm) Liquid side diameter : 6.35

Refrigerant pipe (mm) Gas side diameter : 12.70

INDOOR

Net dimension (mm) W/D/H : 975/220/318

Package dimension (mm) W/D/H : 1035/385/285

Net weight (kg) : 13.0

Gross weight (kg) : 15.0

Noise [dB(A)] (Hi/Mid/Lo/So) : 48/45/41/38

OUTDOOR

Net dimension (mm) : 800/280/550

Package dimension (mm) : 954/409/625

Net Weight (kg) : 34.5

Gross Weight (kg) : 38.5

Noise [dB(A)] : 54

Max Pipe Length(m) : 25

Max Pipe Height(m) : 15

Chargless Piping Length(m) : 5

Amount of additional Refrigerant (g) : 20

Amount of Gas(g) : 860

Power Supply : indoor

Metering Device : capillary tube
