Compressor

Type: Non Inverter

Model

Indoor/Outdoor: HSU-13LPB21

Capacity

Capacity (W): 3516

Capacity (Btu): 12000

Power input (W) Cooling: 1128

CSPF: 3.30

Star Rating: 3

Running current (A) Cooling: 5.10

Power supply (Ph/V/Hz): 1/220-240/50

Air circulation (m/h): 700

Moisture removal (10m/h): 1.6

Refrigerant: R32

Refrigerant pipe (mm) Liquid side diameter: 6.35

Refrigerant pipe (mm) Gas side diameter: 9.52

INDOOR

Net dimension (mm) W/D/H: 805/200/292

Package dimension (mm) W/D/H: 874/270/363

Net weight (kg): 9.2

Gross weight (kg): 11.2

Noise [dB(A)] (Hi/Mid/Lo/So): 40/37/34/29

OUTDOOR

Net dimension (mm): 800/280/550

Package dimension (mm): 954/409/625

Net Weight (kg): 29.0

Gross Weight (kg): 31.0

Noise [dB(A)]: 53

Max Pipe Length(m): 15

Max Pipe Height(m): 10

Chargless Piping Length(m): 5

Amount of additional Refrigerant (g): 20

Amount of Gas(g): 570

Power Supply: indoor

Metering Device: capillary tube
