What's in the box:
Universal Joint x 1pc
Product details of GMB Universal Joint / U-Joint / Coupling GUMZ-6 for Ford Mazda B2500
Brand : GMB
Universal Joint Specifications:
Figure Type = B2
L = Assembly Size: 59.00mm
D = Case Size: 28.00mm
Universal Joint's Snap Ring Specifications:
Diameter= 25.2 mm
Thickness = 2.95 mm
Type : III
Position : Inside Snap Ring
Price quoted is for 1pc
OEM Reference Number
0604-25-060
0604-89-251
0604-89-251A
0604-99-250
0706-89-251
2525-25-060
8BW1-25-060
8BW1-25-065
8BS2-25-060
8BS2-25-060A
D27Z-4758A
GMB's Universal Joint
Drive shaft incorporated with universal joint is widely in use not only in automotive industry but also all other industrial scenes. Purpose: high torque transmission in limited space. GMB is specialized in universal joint, key element of module like drive shaft or propeller shaft. GMB is able to meet different requirements and shaft sizes of OEM customers. GMB also covers global aftermarket with wider range line-up and proudly extends our brand name. This service is realized by our thorough in-house production. GMB maintains production and engineering knowledge and experience to produce universal joints of the highest quality viable under all conditions at economical cost.
Structure
Universal joint consists of spider(cross) and 4 grease-filled roller bearings. It can transmit large torque at low friction. Spider with journal pegs and bearing cases as outer ring were hot forged or cold formed and machined. They are later carburized in furnace so that increased ruggedness and wear resistance are obtained. Parts are finally ground to designed size under severe tolerance. Oil seal as well as dust cover are also in use to protect internal journal area from intrusion of foreign material. Variety of grades and materials are selected to respond to extreme conditions such as very hot / very cold temperatures.
