Product Information
Size (length*width*height): 15cm x 15cm x 15cm
What's in the box:
KTS Billet Compressor Wheel MFSX841Cx 1pc
|
KTS MFS P/N |
X841 |
|
OE MODEL |
HX82 |
|
OE COMPRESSOR WHEEL P/N |
4048022 |
|
OE TURBOCHARGER P/N |
UNK |
|
APPLIED TO ENGINE/VEHICLE |
UNK1 |
|
FITS COMPRESSOR HOUSING |
Custom |
|
NOSE DIAMETER (mm) |
36.50 |
|
INDUCER (mm) |
101.91 |
|
EXDUCER (mm) |
152.04 |
|
TIP EXDUCER (mm) |
- |
|
TIP HEIGHT (mm) |
8.52 |
|
SUPERBACK (mm) |
12.88 |
|
BORE SIZE (mm) |
11.12 |
|
BORE TYPE |
Through |
|
OVERALL HEIGHT (mm) |
71.28 |
|
BLADE NUMBER |
8+8 |
|
ROTATION |
Forward |
