Size (length*width*height): 15cm x 15cm x 15cm
What's in the box:
KTS Billet Compressor Wheel MFSX6A8Cx 1pc
|
KTS MFS P/N |
X6A8 |
|
OE MODEL |
HT60 |
|
OE COMPRESSOR WHEEL P/N |
UNK |
|
OE TURBOCHARGER P/N |
3537074 / 3592512 / 3592678 / 3804502 / 3536811 / 3536095 / 3531733 / 3590615 / 172035 |
|
APPLIED TO ENGINE/VEHICLE |
Cummins Industrial with N14 Euro 2 Engine |
|
FITS COMPRESSOR HOUSING |
OE |
|
NOSE DIAMETER (mm) |
20.00 |
|
INDUCER (mm) |
73.52 |
|
EXDUCER (mm) |
109.00 |
|
TIP EXDUCER (mm) |
116.64 |
|
TIP HEIGHT (mm) |
8.12 |
|
SUPERBACK (mm) |
9.68 |
|
BORE SIZE (mm) |
11.12 |
|
BORE TYPE |
Through |
|
OVERALL HEIGHT (mm) |
54.00 |
|
BLADE NUMBER |
8+8 |
|
ROTATION |
Reverse |
