Product Information
Size (length*width*height): 15cm x 15cm x 15cm
What's in the box:
KTS Billet Compressor Wheel MFSX677Cx 1pc
|
KTS MFS P/N |
X677 |
|
OE MODEL |
HX60 |
|
OE COMPRESSOR WHEEL P/N |
UNK |
|
OE TURBOCHARGER P/N |
UNK |
|
APPLIED TO ENGINE/VEHICLE |
UKN |
|
FITS COMPRESSOR HOUSING |
Custom |
|
NOSE DIAMETER (mm) |
21.00 |
|
INDUCER (mm) |
81.00 |
|
EXDUCER (mm) |
116.00 |
|
TIP EXDUCER (mm) |
- |
|
TIP HEIGHT (mm) |
8.14 |
|
SUPERBACK (mm) |
9.68 |
|
BORE SIZE (mm) |
11.12 |
|
BORE TYPE |
Threaded-M11x1.0LHT |
|
OVERALL HEIGHT (mm) |
76.68 |
|
BLADE NUMBER |
6+6 |
|
ROTATION |
Forward |
