Keterangan
Size (length*width*height): 15cm x 15cm x 15cm
What's in the box:
KTS Billet Compressor Wheel MFSH113Cx 1pc
|
KTS MFS P/N |
H113 |
|
OE MODEL |
HT10 |
|
OE COMPRESSOR WHEEL P/N |
UNK |
|
OE TURBOCHARGER P/N |
UNK |
|
APPLIED TO ENGINE/VEHICLE |
UNK |
|
FITS COMPRESSOR HOUSING |
OE |
|
NOSE DIAMETER (mm) |
12.90 |
|
INDUCER (mm) |
29.97 |
|
EXDUCER (mm) |
50.00 |
|
TIP EXDUCER (mm) |
- |
|
TIP HEIGHT (mm) |
4.40 |
|
SUPERBACK (mm) |
0.10 |
|
BORE SIZE (mm) |
6.35 |
|
BORE TYPE |
Through |
|
OVERALL HEIGHT (mm) |
23.12 |
|
BLADE NUMBER |
6+6 |
|
ROTATION |
Forward |
