Keterangan
Size (length*width*height): 15cm x 15cm x 15cm
What's in the box:
KTS Billet Compressor Wheel MFS6006Cx 1pc
|
KTS MFS P/N |
6006 |
|
OE MODEL |
GT6041BLN |
|
OE COMPRESSOR WHEEL P/N |
UNK |
|
OE TURBOCHARGER P/N |
701026-0019/0001/0020/0022/0023> |
|
APPLIED TO ENGINE/VEHICLE |
Caterpillar 452705-0028(10R-5421> |
|
FITS COMPRESSOR HOUSING |
OE |
|
NOSE DIAMETER (mm) |
34.90 |
|
INDUCER (mm) |
102.75 |
|
EXDUCER (mm) |
141.27 |
|
TIP EXDUCER (mm) |
- |
|
TIP HEIGHT (mm) |
9.77 |
|
SUPERBACK (mm) |
37.98 |
|
BORE SIZE (mm) |
13.48 |
|
BORE TYPE |
Boreless-1/2-13G-LHT |
|
OVERALL HEIGHT (mm) |
115.30 |
|
BLADE NUMBER |
6+6 |
|
ROTATION |
Forward |
