Product Information
Size (length*width*height): 15cm x 15cm x 15cm
What's in the box:
KTS Billet Compressor Wheel MFS4706Cx 1pc
|
KTS MFS P/N |
4706 |
|
OE MODEL |
GTA4508R |
|
OE COMPRESSOR WHEEL P/N |
UNK |
|
OE TURBOCHARGER P/N |
800270-0001/451888-0045 |
|
APPLIED TO ENGINE/VEHICLE |
CAT> |
|
FITS COMPRESSOR HOUSING |
Custom |
|
NOSE DIAMETER (mm) |
18.97 |
|
INDUCER (mm) |
79.85 |
|
EXDUCER (mm) |
108.04 |
|
TIP EXDUCER (mm) |
116.65 |
|
TIP HEIGHT (mm) |
8.45 |
|
SUPERBACK (mm) |
9.52 |
|
BORE SIZE (mm) |
8.25 |
|
BORE TYPE |
Threaded-M8x1.25LHT |
|
OVERALL HEIGHT (mm) |
64.00 |
|
BLADE NUMBER |
7+7 |
|
ROTATION |
Forward |
