Technical Specifications

Output
Max Configurable Power (Watts) : 2.4kWatts / 3.0kVA
Output Voltage Note : Configurable for 220 : 230 or 240 nominal output voltage
Efficiency at Full Load : 88.0 %
Output Voltage Distortion : 3 %
Output Frequency (sync to mains) : 50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages : 220 V, 240 V
Load Crest Factor : 3 : 1
Topology : Double conversion online
Waveform type : Sine wave
Transfer Time : 4 ms typical
Bypass : Internal bypass (automatic and manual)

Input
Input frequency : 40 - 70 Hz Auto sensing
Input voltage range for main operations : 110 - 285 Half load, 160 - 280 Full loadV
Number of Power Cords : 1
Efficiency at Full Load : 88.0 %
Other Input Voltages : 220 V, 240 V

Batteries & Runtime
Battery type : Lead-acid battery
Typical recharge time : 5.5hour(s)
Nominal Battery Voltage : 72 V
Expected Battery Life (years) : 3 - 5
Battery Charge Power (Watts) : 350 Watts
Runtime : View Runtime Graph
Efficiency : View Efficiency Graph

Communications & Management
Interface Port(s) : DB-9 RS-232, USB
Control panel : Multifunction LCD status and control console
Audible Alarm : Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Available SmartSlot™ Interface Quantity : 1

Surge Protection and Filtering
Surge energy rating : 600Joules

Physical
Maximum Height : 336MM, 33.6CM
Maximum Width : 425MM, 42.5CM
Maximum Depth : 425MM, 42.5CM
Net Weight : 45.9KG
Color : Black

Environmental
Operating Temperature : 0 - 40 °C
Operating Relative Humidity : 0 - 95 (Non-condensing) %
Operating Elevation : 0 - 3000meters
Storage Temperature : -20 - 50 °C
Storage Relative Humidity : 0 - 95 (Non-condensing) %
Storage Elevation : 0 - 15000meters
Audible noise at 1 meter from surface of unit : 50.0dBA
Online thermal dissipation : 910.0BTU/hr
Protection Class : IP20

Conformance
Approvals : CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, TISI
Standard warranty : 2 years repair or replace
