AI Base Smart Parking Mode - 24/7 Precision Monitoring for DDPAI N5 Dual

AI Base Radar Motion Detection

The AI millimeter-wave radar monitors car surroundings. Upon detection, the camera automatically records, saving video 10 seconds before and 10 seconds after the event.

AI on guard

Recognizing repeat visitors and capturing their every move. Our advanced motion detection algorithm goes beyond collisions, identifying and recording events like scratches and theftensuring you never miss a thing.

Battery-friendly Monitoring

Efficiently monitors motion with minimal power (5mW), activating and recording only during detected motion or impact. Achieves an 87% reduction in operation time compared to regular motion sensors, offering up to 15 days of recordings.

Protect Your Vehicle Battery

DDPAI's IPS Power Management Technology combats battery depletion during parking surveillance by intelligently reducing voltage, ensuring prolonged battery health.

Radar Module Installation (Optional Accessory)

Step 1: PlugtheType-C connector of theOBDpower cable into the Type-C port of the radar module.

Step 2: Connect the other end of theOBDpower cable tothe OBDport of the vehicle.

Step 3: PlugtheType-C connector ofthe radarcable into the Type-C port of the Dash Cam.

Step 4: Attach the electrostatic sticker to the recommended area as shown in the figure below. Remove the protective film from the radar, attach the adhesive side to the windshieldclose to the Dash Cam (make sure the indicatorof the radar module is facing the windshield).

Take Note

The figure above is for reference only, please refer to the actual situation.

Do NOT place the radar behind the rearview mirror. Because rearview mirror obstruction may affect radar performance.

The default low-voltage protection value is 12V. When the car battery voltage is lower than the set value, the power-off protection will be activated to ensure that the car battery does not lose power during parking monitoring.

The step-down line supplies power from 12V to 5V and has a built-in high-precision voltage detection chip to output a more stable voltage.

The OBD power cable is ONLYcompatible with DDPAI Dash Cam.

The OBD power cable only obtains power from the OBD port and will not cause safety hazards to the car.

Please use and store the OBD power cable within the specified temperature range(Working temperature:-20to 70, storage temperature: -30to 85).

Whats in the box

- Radar Module

- OBD Hardwire Kit

- User Manual

- Electrostatic Sticker

- 3M Adhesive
