What's in the box:
Engine Valve x 4pcs
(4pc) Münster Engine Valve Intake Inlet (30.0mm) 14711-P08-000 for Honda Civic SR4 SO4 S04 SX8 S5A V-Tec 1.6 SOHC SC SingleCam D16
100% Original Münster Engine Valves
100% Made In Japan
Best Quality Product
We have distributed many types of model
Price quoted for 4pcs
Please verify the quantity sizes that you required against the published size to ensure the correct product is being ordered as below :
Engine Valve details below :
No. of Pistons/Cylinders :- 4
No. of Engine Valve per vehicle :- Exhaust : 8pcs + Intake : 8pcs
D1 : Seat Diameter : Exhaust : 26.0mm / Intake : 30.0mm
D2 : Stem Diameter : Exhaust : 5.5mm / Intake : 5.5mm
L : Total Length : Exhaust : 116.0mm / Intake : 118.6mm
A : Face Angle : Exhaust : 45° / Intake : 45°
Head Type : Exhaust : ST / Intake : ST
Stem Ends Type : Exhaust : CG / Intake : CG
Cross Reference :
Exhaust Valve :-
14721-P08-000
14721-P1J-L00
Intake Valve :-
14711-P08-000
14711-P1J-L00
Engine :
D16
Münster are making efforts to supply highly functional engine valve that can support not only durability, downsizing, weight saving, but also leading-edge design such as the improvement of fuel efficiency and low emission.
The engine valve plays an important role in the combustion chamber inside the engine.
As engine valve opens and closes several thousand times per minute in combustion over 800°C, heat resistance and wear resistance are essential.
